Reliable UV Disinfection for Safer Water
UV disinfection provides a chemical-free barrier against harmful microorganisms in drinking water, process water, and wastewater applications. By inactivating chlorine-resistant pathogens such as Giardia and Cryptosporidium, UIEX UV systems help reduce microbiological risk without changing the taste, odor, or chemistry of the water.
Water contamination can occur at many points in municipal, industrial, and commercial water systems, especially where aging infrastructure, variable source-water quality, or continuous production processes increase the risk of microbial growth. UIEX UV water disinfection systems are designed to deliver effective, low-maintenance microbial control for a wide range of critical water applications.
Engineered for Reliable UV Performance
Product Series at a Glance
Series | Positioning | Best For |
WDU-LP | Compact low-pressure UV | Clear, high-UVT water and compact hygienic installations |
WDU-MP | Single-lamp medium-pressure UV | Hygienic, higher-duty process water |
WDX-MP | Multi-lamp medium-pressure UV | High-flow industrial water and engineered pipeline systems |
SDU-MP | Medium-pressure for Syrup | Liquids with extremely low UV transmittance |
Explore our Product Series
WDU-LP Series Compact Low-Pressure UV Disinfection Systems
Designed for clear, high-UVT water applications where compact installation, hygienic process integration, stable UV performance and efficient energy control are required
Best Suited For
• Clear water and high-UVT water
• Compact hygienic installations
• Low-to-medium flow process water
• Stable disinfection with efficient energy use
Key Specifications
| UV Technology | low-pressure UV |
Model Range | 65W–600W |
Lamp Quantity | 1–2 lamps |
Lamp Life | 16,000(A) hours |
Power Control | Fixed or adjustable UV power |
Monitoring | Online UV sensor / ÖNORM-certified option |
Chamber | 316L stainless steel, 0.6 μm Ra internal finish |
Connection | Sanitary Tri-clamp fitting or flange |
Control | PLC + HMI, Local / Modbus communication |
Operating Pressure | Max. 10 bar |
Model Range
Configuration | Models | Best Fit |
Single-Lamp Models | WDU-LP65 / LP100 / LP200 / LP300… | Compact systems, smaller flow, high-UVT water |
Dual-Lamp Models | WDU-LP400 / LP600… | Higher capacity within compact low-pressure design |
Compare WDU-LP Configurations →
Download WDU-MP Brochure
SDU-MP Series High-Output Low-Pressure UV Systems for Medium to Large Flow Applications
Designed for medium to large flow applications where long lamp life, multi-lamp configuration and reliable UV dose delivery are required
Best Suited For
• Medium-to-large flow water treatment
• Long lamp life and lower operating cost
• Multi-lamp UV dose delivery
• High-UVT process water or larger-flow lower-UVT applications
Key Specifications
| UV Technology | High-output low-pressure UV |
Main Wavelength | 253.7 nm |
Lamp Power Options | 200W / 300W |
Lamp Quantity | 3 / 4 / 6 / 8 lamps |
Lamp Life | 16,000 hours |
Power Adjustment | 50%–100% |
System Power Range | 720W–3.0kW |
Monitoring | Online UV intensity sensor |
Model Range
Configuration | Best For | Range |
200W Lamp Group | Medium-flow, high-UVT water applications | 3–8 lamps, 720W–1950W system power |
300W Lamp Group | Large-flow or lower-UVT water applications | 3–8 lamps, 1.1kW–3.0kW system power |
Compare WDU-LPH Configurations →
Download WDU-LPH Brochure
Request Recommendation
WDU-MP Series Medium-Pressure UV Systems for Hygienic and High-Dose Process Water
Delivering higher UV dose for purified water, process water and hygienic applications where compact design, stable dose delivery and reliable system integration are required
Best Suited For
• Purified water and process water
• Hygienic design requirements
• Medium-to-high-duty treatment
• Compact medium-pressure UV configuration
• Stable control and system integration
Key Specifications
| UV Technology | Single-lamp medium-pressure UV |
Model Range | 1–12 kW |
Lamp Quantity | 1 lamp |
Lamp Life | 8,000 hours |
UV Output Range | Broad-spectrum UV, 200–400 nm |
Power Control | Fixed or adjustable UV power |
Monitoring | Online temperature detection, optional UV monitoring |
Wiper System | Integrated wiper system |
Chamber | 316L stainless steel, 0.6 μm Ra internal finish |
Connection | Sanitary Tri-clamp fitting or flange |
Control | PLC + HMI, Local / Modbus communication |
Operating Pressure | Max. 10 bar |
Model Range
Configuration | Best For | Range | Service Access |
Compact MP Configuration | Purified water and hygienic process water | 2–3 kW | Single-end access |
High-Duty MP Configuration | Medium-to-high-duty process and industrial water | 6–12 kW | Dual-end access |
Compare WDU-MP Configurations →
Download WDU-MP Brochure
Request Recommendation
WDX-MP Series Medium-Pressure UV Systems for High-Flow Industrial Water
Designed for high-flow industrial water treatment and engineered pipeline systems where multi-lamp configuration, flanged integration, and wide-range power control are required
Best Suited For
• High-flow industrial water treatment
• Engineered pipeline systems
• Large-flow or variable-load operation
• Petrochemical, power generation, aquaculture, municipal / reuse water
• Heavy-duty industrial environments
